Russian Imperial Yacht Kolkhida

Share This:

The Russian Imperial Yacht Kolkhida is a real beauty. She has a nicely curved deck, three masts, a beautiful bow… She has all the characteristics of the yachts in that era. She was 67.1 meters long and 8.7 meters wide. Her steam engine was producing 1200 hp and she could do 14 knots.
The scale model plans of this yacht is a single page, not so detailed but fine. The parts are shown seperately.

Kolkhida1914-1917
parts :

1 – bowsprit, 2 – jack-staff, 3 – figurehead, 4 – stem, 5 – bollard, 6 – anchor winch, 7 – admiralty anchor, 8 – spire, 10 – 75-mm bow gun, 11 – bow hatch, 12 – winch, 13 – damper for cable, 14 – foremast, 15 – Flag 16 – derrick, 17 – cargo door, 18 – skylight, 19 –  longboat, 20 – left side light, 21 – Spotlight 22 – Compass 23 – steering wheel, 24 –  boat, 25 – mainmast, 26 – blackened part of the mainmast, 27 – Pennant, 28 – Transition bridge, 29 – vosmiveselny whaler, 30 – grappling rostra, 31 – sloop-beam, 32 – mizzen-mast, 33 – flag on the gaff, 34 – the rudder, 35 – 75-mm cannon fodder, 36 – propeller, 37 – steering wheel, 38 – valance stern, 39 – the flagpole.

Click here to download the yacht Kolkhida
