Ocean Rescue Tugs Bars and Jahuar

Share This:

scale model hobby rc bars ocean rescue tugboat

We have two Soviet ocean going rescue tugs here. The “Bars” and “Jahuar” . Yeah as you guessed, their names mean “Leopard” and “Jaguar” . The sister tugboats were built in 1978 in Leningrad.

They have high speed and maneuverability. They have so many rescue equipment on board including diving gear and decompression chamber. This feature also give them exploration vessel facility. But mainly it is for patching, welding or inspecting underwater. There are pumps capable of pumping 3500 cubic meters of water in an hour.

hobby scale model plans bars jahuar ocean going tugs

The stern bitt can withstand 300 tons and the drum 60 tons. The ships are also equipped with fire fighting gear.

Can not find so much info about them but they seem to have name changes. They may even be scrapped already…

The plan set are high quality tiff images. Scale model ship plans are very clear and easy to read. There could be more details but still enough to build a model ship.

scale model building hobby bars tugboat model

Parts on the plan set: (direct translate by google)

1 – anchor-hole corner, 2 – anchor Hall 3 – Fender, 4 – bow towing Clusaz 5 – bow anchor lantern lamp 6 – mooring hawse, 7 – the ship’s bell, 8 – rubbing beam, 9 – storm porch, 10 – pnevmokranets 11 – bow cargo boom, 12 – side lantern, 13 – magnetic compass binnacle, 14 – Spotlight 15 – master stream nozzle, 16 – foremast, 17 – lantern lower masthead fire, 18, 22 – Emergency fire lantern, 19, 21 – radar antenna, 20, 24 – lantern tug fire 23 – antenna finder, 25 – lantern klotikovogo fire 26 – radio antenna, 27 – davit, 28 – locked motor lifeboat 29 – the crossbar for exercise Crew, 30 – chimney, 31 – control cabin aft cargo boom and towing winch, 32 – mainmast, 33 – second upper lantern masthead light, 34 – second lantern klotikovogo fire 35 – aft cargo boom 36 – railing, 37 – bleeder divers, 38 – lantern wakefield fire 39 – lantern gakabortnogo fire 40 – towing bitt, 41 – towing arc 42 – aft towing hawse with roller, 43 – aft anchor lantern fire 44 – rudder, 45 – mooring cleats, 46 – directing nozzle propeller 47 – cargo winch aft boom, 48 – topenantnaya winch, 49 – cage divers to descend, 50 – gangway, 51 – board keel, 52 – large working boat 53 – small work boat, 54 – boat winch, 55 – automatic inflatable liferaft container, 56 – gyro repeater, 57 – cargo winch bow arrows, 58 – tunnel thruster, 59 – front cargo door, 60 – damper for cable 61 – remote control spiers, 62 – volnootboynik, 63 – Windlass, 64 – screw anchor chain stopper, 65 – chain stopper anchor chain, 66 – Deck Clusaz 67 – cap klyuzovoy pipe 68 – Fan, 69 – towing bollard, 70 – similar to the forepeak hatch, 71 – bulb.

Click here to download the plans
